Hey guys! So, you've got your hands on the MSI MAG Coreliquid E360, and you're ready to keep your CPU icy cool. Awesome! This guide will walk you through the entire installation process, ensuring everything goes smoothly. Whether you're a seasoned PC builder or a newbie, we've got you covered. Let's dive in!

What's in the Box?

Before we start, let's make sure you have everything you need. Inside the box, you should find:

• The MSI MAG Coreliquid E360 cooler itself (radiator, pump/block combo).
• Three 120mm fans.
• Mounting brackets for Intel and AMD CPUs.
• Screws for attaching the fans to the radiator.
• Screws and standoffs for mounting the cooler to your case and CPU socket.
• A tube of thermal paste (or pre-applied thermal paste on the block).
• Cables for connecting the fans and pump to your motherboard.
• Installation manual. I recommend to check it!

Make sure you have all these components. If anything is missing, contact the retailer or MSI support.

Preparing for Installation

Before you start wrestling with hardware, preparation is key. First, turn off your computer and unplug it from the power outlet. This is crucial for your safety and the safety of your components.

Next, gather your tools. You'll likely need a Phillips head screwdriver, and possibly a wrench or pliers depending on your case. Also, a well-lit workspace is essential. Good lighting helps you see what you're doing and prevents accidental slips.

Now, let's talk about compatibility. The MSI MAG Coreliquid E360 supports a wide range of Intel and AMD sockets. Check the manual to ensure your CPU socket is supported. Common supported sockets include:

• Intel: LGA 115x, LGA 1200, LGA 1700
• AMD: AM4, AM5

Finally, consider the placement of the radiator. The E360, being a 360mm cooler, requires a case that can accommodate a 360mm radiator. Common locations are the top or front of the case. Ensure you have enough clearance and that the radiator won't interfere with other components like RAM or the motherboard's VRM heatsinks. A little planning goes a long way in preventing headaches later.

Step-by-Step Installation Guide

Alright, let's get down to the nitty-gritty. Here's a step-by-step guide to installing your MSI MAG Coreliquid E360.

Step 1: Install the Fans on the Radiator

First, take the three 120mm fans and align them with the radiator. The fans should be oriented to blow air through the radiator. Usually, this means the fan blades will be facing the radiator when you look at them from the side where you'll be mounting the radiator. Use the provided screws to secure the fans to the radiator. Don't overtighten the screws; just snug them up. Make sure all the cables of the fans are accessible and facing to the same side. This will make your life easier when connect them to the motherboard.

Step 2: Mount the CPU Backplate

For Intel systems, you'll likely need to install a backplate behind the motherboard. This backplate provides a secure mounting point for the CPU block. Consult the manual to identify the correct backplate and orientation for your specific socket. Align the backplate with the holes on your motherboard and secure it with the provided standoffs.

For AMD systems, you might be able to use the stock AMD backplate that comes with your motherboard. If so, remove the stock cooler mounting brackets while leaving the backplate in place. If your cooler requires a different backplate, follow the instructions in the manual.

Step 3: Install the Standoffs

Next, screw the standoffs into the backplate. These standoffs will hold the CPU block in place. Again, make sure you're using the correct standoffs for your CPU socket. Tighten them securely, but don't overtighten.

Step 4: Apply Thermal Paste

If your cooler doesn't have pre-applied thermal paste, now's the time to apply it. A small, pea-sized amount in the center of the CPU is usually sufficient. The pressure from the CPU block will spread the paste evenly. Avoid using too much thermal paste, as it can actually reduce cooling performance. If your cooler has pre-applied thermal paste, remove the protective cover before proceeding.

Step 5: Mount the CPU Block

Carefully align the CPU block with the standoffs and lower it onto the CPU. Make sure the block is making full contact with the CPU. Use the provided screws to secure the block to the standoffs. Tighten the screws in a crisscross pattern to ensure even pressure. Again, don't overtighten. Tighten until snug and secure.

Step 6: Mount the Radiator

Now it's time to mount the radiator inside your case. Position the radiator in your desired location (top or front) and use the provided screws to secure it to the case. Ensure the radiator is securely mounted and doesn't wobble. Also, make sure the tubes are not kinked or bent sharply, as this can restrict coolant flow.

Step 7: Connect the Cables

Connect the fan cables to the fan headers on your motherboard. Consult your motherboard manual to identify the fan headers. You can use fan splitters if you don't have enough headers. Connect the pump cable to the CPU_FAN header or a dedicated pump header on your motherboard. This is crucial for the pump to function properly. Finally, connect any RGB or ARGB cables to the appropriate headers on your motherboard or a separate RGB controller.

Step 8: Cable Management

Good cable management is essential for airflow and aesthetics. Use zip ties or Velcro straps to bundle and route the cables neatly. Keep the cables away from the fans and other moving parts. A clean build not only looks better but also helps with cooling performance.

Configuring BIOS Settings

Once you've installed the cooler, it's time to configure the BIOS settings. Boot up your computer and enter the BIOS setup (usually by pressing Delete, F2, or F12 during startup). Look for the fan control settings. Make sure the CPU_FAN header is set to PWM mode (if your fans are PWM fans). You can also adjust the fan curves to optimize cooling performance and noise levels. Monitor the CPU temperature to ensure the cooler is working effectively. If the temperatures are too high, adjust the fan curves or re-seat the cooler.

Troubleshooting Common Issues

Even with careful installation, you might encounter some issues. Here are some common problems and their solutions:

• High CPU Temperatures: Check if the cooler is making proper contact with the CPU. Reapply thermal paste if necessary. Also, ensure the pump is running and the fans are spinning.
• Pump Noise: Some pump noise is normal, but excessive noise could indicate a problem. Check if the pump is properly connected and receiving power. Also, make sure there are no air bubbles in the system. Tilting the case can sometimes help remove air bubbles.
• Fan Noise: Adjust the fan curves in the BIOS to reduce fan speed at lower temperatures. You can also replace the fans with quieter models.
• RGB Issues: Ensure the RGB cables are properly connected to the correct headers. Check the RGB software for any configuration options.
• System Not Booting: Double-check all connections and ensure the cooler is properly installed. Reseat the RAM and graphics card to rule out any other issues.

Maintaining Your Cooler

To keep your MSI MAG Coreliquid E360 running smoothly, it's important to perform regular maintenance. Dust can accumulate on the radiator and fans, reducing cooling performance. Use a can of compressed air to clean the radiator and fans regularly. Also, check the coolant level periodically. If the coolant level is low, you may need to refill the system (although this is less common with closed-loop coolers).

Conclusion

Installing the MSI MAG Coreliquid E360 might seem daunting at first, but with a little patience and attention to detail, it's a straightforward process. By following this guide, you'll have your CPU running cool and quiet in no time. Happy building, and enjoy your gaming sessions with your newly cooled system! Remember to always double-check the manual for specific instructions related to your motherboard and CPU. Good luck, and have fun!
