Hey guys! So, you've got yourself a MikroTik LHG 5 and are ready to set it up? Awesome! This guide will walk you through configuring your LHG 5 step-by-step, making it super easy. We'll cover everything from initial access to advanced settings, ensuring you get the best performance out of your device. Whether you're setting up a point-to-point link or extending your network, this guide has got you covered. Let's dive in!

Initial Setup and Access

First things first, let's get your MikroTik LHG 5 connected and accessible. This part is crucial because you can't configure anything if you can't even talk to the device, right? So, let's break it down:

Connecting the Hardware

• Powering Up: Connect the LHG 5 to power using the PoE (Power over Ethernet) injector that comes with it. Plug an Ethernet cable from the PoE injector's 'PoE' port to the LHG 5, and another Ethernet cable from the 'LAN' port to your computer or network switch. This will provide both power and data connectivity to the device.
• Direct Connection: For the initial setup, it's best to connect directly to your computer. This avoids any network configuration conflicts that might occur if you connect through a router or switch that has a conflicting IP address.
• Check Indicators: Once connected, check the LED indicators on the device. They should light up, indicating that the device is receiving power and attempting to establish a network connection. If the LEDs don't light up, double-check your cable connections and power source.

Accessing the RouterOS

• Default IP Address: By default, MikroTik devices come with an IP address of 192.168.88.1. Your computer needs to be on the same subnet to communicate with it. Configure your computer's Ethernet adapter with a static IP address, such as 192.168.88.2, and a subnet mask of 255.255.255.0. Leave the gateway field blank for now.
• Using WinBox: Download and install WinBox, MikroTik's configuration utility, from the MikroTik website. WinBox is a lightweight application that provides a graphical interface to manage your MikroTik router. It's available for Windows, and you can also run it on other operating systems using Wine.
• Connecting via WinBox: Open WinBox, and it should automatically discover your MikroTik LHG 5 on the network. If it doesn't, manually enter the IP address (192.168.88.1) in the 'Connect To' field. The default username is 'admin', and there's no password by default. Click 'Connect' to access the RouterOS interface.

First Login and Basic Configuration

• Default Credentials: When you log in for the first time, WinBox will prompt you to change the default password. It's extremely important to set a strong password to secure your device from unauthorized access. Choose a password that is complex and difficult to guess.
• System Identity: Go to 'System' > 'Identity' and set a unique name for your LHG 5. This helps you easily identify the device, especially if you have multiple MikroTik devices on your network. For example, you might name it 'LHG5-Office' or 'LHG5-Client'.
• Firmware Update: Check for firmware updates by going to 'System' > 'Packages' > 'Check For Updates'. Keeping your device's firmware up to date ensures that you have the latest features, security patches, and bug fixes. If updates are available, download and install them. The device might reboot during the update process.

Configuring Wireless Settings

Now, let's get into the heart of the configuration: setting up the wireless interface. The MikroTik LHG 5 is designed for wireless connectivity, so this is where you'll spend most of your time.

Wireless Mode

• Access Point (AP): If you're using the LHG 5 as a base station to provide wireless connectivity to other devices, you'll want to configure it as an Access Point. Go to 'Wireless', select your wireless interface (usually wlan1), and set the 'Mode' to 'ap-bridge'. This mode allows multiple clients to connect to the LHG 5 and bridge their traffic to the wired network.
• Station: If you're using the LHG 5 to connect to an existing wireless network, set the 'Mode' to 'station' or 'station-bridge'. The 'station' mode connects to an AP and acts as a client, while 'station-bridge' also bridges the client's wired network to the wireless network.
• Point-to-Point: For point-to-point links, use the 'bridge' mode on both ends. One LHG 5 will act as the AP, and the other will act as the station. Ensure both devices are configured to use the same frequency and wireless protocol for optimal performance.

Frequency and Channel Width

• Frequency Selection: Choose a frequency that is appropriate for your region and doesn't interfere with other wireless networks. The 5 GHz band offers multiple channels, but some may be restricted by local regulations. Use a spectrum analyzer tool, if available, to find the least congested channel. In WinBox, you can specify the frequency manually or use the 'auto' option, which lets the device automatically select the best channel.
• Channel Width: The channel width determines the amount of bandwidth available for wireless communication. Wider channels provide higher data rates but are also more susceptible to interference. Common channel widths include 20 MHz, 40 MHz, and 80 MHz. Start with 20 MHz for a stable connection and increase it if needed, monitoring for interference.

Security Settings

• Wireless Security: Securing your wireless network is crucial to prevent unauthorized access. The most common security protocol is WPA2-PSK. Go to the 'Security Profiles' tab in the Wireless settings and create a new security profile. Set the 'Mode' to 'dynamic keys', check the 'WPA2 PSK' box, and enter a strong password in the 'WPA2 Pre-Shared Key' field. Apply this security profile to your wireless interface.
• Hide SSID: For added security, you can hide the SSID (Service Set Identifier) of your wireless network. This prevents unauthorized users from easily discovering your network. However, hiding the SSID also means that users will need to manually enter the network name to connect.

Advanced Wireless Settings

• TX Power: Adjusting the transmit power (TX Power) can help optimize the range and performance of your wireless link. Higher TX power increases the signal strength but can also cause interference with other devices. Lower TX power reduces interference but may decrease the range. Experiment with different TX power levels to find the best balance for your specific environment.
• Antenna Gain: The LHG 5 has a built-in high-gain antenna. Ensure that the antenna alignment is optimized for the best signal strength. Minor adjustments to the antenna direction can significantly improve the link quality.

Network Configuration

With the wireless settings configured, let's move on to the network configuration. This involves setting up IP addresses, routing, and other network services.

IP Addressing

• Static IP Address: Assigning a static IP address to your LHG 5 ensures that it always has the same address on your network. This is important for consistent access and management. Go to 'IP' > 'Addresses' and add a new IP address for your LHG 5. Choose an IP address within your network's subnet and specify the interface it should be assigned to (e.g., wlan1 or ether1).
• DHCP Client: If you want your LHG 5 to automatically obtain an IP address from a DHCP server, configure the DHCP client on the appropriate interface. Go to 'IP' > 'DHCP Client' and add a new DHCP client. Select the interface that should receive the IP address from the DHCP server.

Routing

• Default Gateway: If your LHG 5 needs to access the internet, you'll need to configure a default gateway. The default gateway is the IP address of your router or internet gateway. Go to 'IP' > 'Routes' and add a new route. Set the 'Dst. Address' to '0.0.0.0/0' and the 'Gateway' to the IP address of your router.
• Static Routes: You can also configure static routes to direct traffic to specific networks. This is useful for complex network setups with multiple subnets. Add a new route and specify the destination network in the 'Dst. Address' field and the gateway to reach that network in the 'Gateway' field.

Firewall

• Basic Firewall Rules: The MikroTik RouterOS has a powerful firewall that can protect your network from unauthorized access. Go to 'IP' > 'Firewall' and configure basic firewall rules. A common practice is to drop all incoming connections from the internet except for established and related connections. This helps prevent unwanted traffic from reaching your network.
• NAT (Network Address Translation): If you have multiple devices behind your LHG 5 that need to access the internet, you'll need to configure NAT. NAT translates the private IP addresses of your internal devices to the public IP address of your LHG 5. Go to 'IP' > 'Firewall' > 'NAT' and add a new NAT rule. Set the 'Chain' to 'srcnat', the 'Out. Interface' to the interface connected to the internet, and the 'Action' to 'masquerade'.

Advanced Settings and Optimization

Now that you've got the basics covered, let's explore some advanced settings and optimization techniques to get the most out of your MikroTik LHG 5.

Bandwidth Management (QoS)

• Simple Queues: Use simple queues to manage bandwidth and prioritize traffic. Go to 'Queues' > 'Simple Queues' and add new queues. You can specify the target IP address or network, the maximum bandwidth, and the priority. This allows you to ensure that critical applications receive the bandwidth they need, even during periods of high network usage.
• Queue Trees: For more advanced QoS configurations, use queue trees. Queue trees allow you to create a hierarchical structure of queues, providing fine-grained control over bandwidth allocation. This is useful for complex network environments with multiple types of traffic.

Monitoring and Troubleshooting

• Traffic Monitoring: Use the Torch tool to monitor real-time traffic flowing through your LHG 5. Go to 'Tools' > 'Torch' and select the interface you want to monitor. Torch displays detailed information about the traffic, including source and destination IP addresses, protocols, and bandwidth usage.
• Ping and Traceroute: Use the Ping and Traceroute tools to diagnose network connectivity issues. Ping sends ICMP echo requests to a destination and measures the round-trip time. Traceroute displays the path that packets take to reach a destination.

Security Hardening

• Disable Unnecessary Services: Disable any services that you don't need to reduce the attack surface of your LHG 5. Go to 'IP' > 'Services' and disable services like Telnet and FTP if you're not using them.
• Access List: Use access lists to restrict access to your LHG 5. Go to 'IP' > 'Firewall' > 'Filter Rules' and add rules to allow access only from specific IP addresses or networks. This prevents unauthorized users from accessing your device.

Conclusion

Alright, you've made it through the configuration of your MikroTik LHG 5! From initial setup to advanced optimization, you now have a solid understanding of how to configure your device for various scenarios. Whether you're creating a point-to-point link or extending your network, the MikroTik LHG 5 is a powerful tool in your arsenal. Keep experimenting with different settings and configurations to fine-tune your network and achieve the best possible performance. Happy networking, guys!
